Webhooks

Webhooks allow TVS to send real-time event data to your application or service. Consider this guide by ChrisKewl where he integrates TVS into a real cable box using a Raspberry Pi and a 7-segment display. There is a server running on the Pi that receives the webhook events and updates the 7-segment display accordingly.

All webhook requests are sent by TVS as HTTP GET requests, with values being query parameters in the URL.

This is one-way communication from TVS to your service. Being a static webapp, you can’t send data back this way. (There is a way to send commands to TVS using the remote control API)

All webhooks are optional and live in the webhooks section of your configuration file. The tokens ({channel}, {isManualInput}, {volume}, {isMuting}, etc.) are replaced with the appropriate values when the webhook is called and need to be typed exactly like that (with the brackets) in your URL.

webhooks:
  channelChange: http://your-server/receive_update?channel={channel}&manual={isManualInput}
  volumeChange: http://your-server/receive_update?volume={volume}
  muteChange: http://your-server/receive_update?isMuting={isMuting}

---

channelChange

Type: string

URL called whenever the channel changes.

Supported tokens:

• {channel}: The new channel number. Example: 5, 12, 101.123 (subchannels), -1 (line input), 0 (MENU).
• {isManualInput}: true if the channel change came from direct/manual channel entry, otherwise false.

---

volumeChange

Type: string

URL called whenever the volume changes.

Supported tokens:

• {volume}: The updated volume level. Range is 0 to 50 in multiples of 5, so 0, 5, 10, …, 45, 50

---

muteChange

Type: string

URL called whenever mute state changes (mute or unmute).

Supported tokens:

• {isMuting}: true when muted, false when unmuted.
